5020826 1543326 7542439 7515472 Rear Control Arm Bushing Kit For Polaris

Premium Quality Replacement Part
Rear Upper Left or Right Control Arm Bushing Kit
Compatible with Polaris Models:
Sportsman 450 HO 2×4 2016-2017
Sportsman 570 EPS 2016-2017
Sportsman 570 Touring 2016-2017
Sportsman 570 6×6 Big Boss 2017-2023
Sportsman X2 570 EPS 2017
Sportsman SP 570 EPS 2016
Order Includes:
2 x Long Pivot Shaft: 5020826
Length : 74 mm – 2 91 in
Inner Diameter : 10 mm – 0.39 in
Outer Diameter : 16 mm – 0.62 in
Material: Steel
4 x Bushing: 1543326
Length: 29 7mm – 1 17 in
Inner Diameter: 16mm – 0 6 in
Head Diameter: 31 5mm – 1 24 in
Tube Diameter: 21mm – 0 82 in
Material: Plastic
2 x Nut: 7542439, 7542453
Width: 11.2mm – 0 44 in
Inner Diameter: 8 mm – 0 31 in
Outer Diameter: 14.2 mm – 0 55 in
Thread Size: 3/8-24
Material: Iron
2 x Bolt: 7515472
Length: 100.5 mm – 3.95 in
Stud Length: 28mm – 1.1 in
Head Diameter: 14 mm – 0.55 in
Thread Size: M10-1.0
Note: Installs On Location (A) & (B) In Second Picture
Rear Upper Control Arm Part Number:
Left: 1017747-458, 1017747-067
Right: 1017748-458 1017748-067
Rear Lower Control Arm Part Number:
Left: 1015888-458, 1015888-067
Right: 1015889-458, 1015889-067
Knuckle Part Number:
Left & Right: 5135563
